Product Introduction

As a professional manufacturer of fiber optic components, we provide high-performance Unequal Split Mini Fiber Optic Splitter. It supports 1x2 unequal splitting ratios (1:9, 1:19 optional, customizable), compatible with SC/APC, SC/UPC connectors (LC/FC optional). Our mini FBT splitters are engineered for high-density environments where standard splitters won't fit. All products have passed strict factory testing, ensuring reliable quality and long service life.

Core Advantages

1. Unequal Precision: Supports 1x2 non-uniform splitting (1:9, 1:19, or custom) for precise power distribution.

2. Ultra-Mini Form Factor: Compact design (approx. 42x5x3.5mm) saves installation space in high-density environments.

3.  Industrial-Grade Stability: Operating temperature from -40°C to +85°C with excellent corrosion resistance.

4. Advanced FBT Technology: Fused Biconical Taper process ensures low signal attenuation and long-term reliability.

5. Fully Customizable: Flexible options for split ratios, fiber types (G.652D/G.657.A), and connectors (SC, LC, FC).

6. Certified Quality: 100% factory tested and compliant with Telcordia GR-1209/1221-CORE and RoHS standards.

Technical Specifications

Application Scenarios

1. FTTH & PON Networks: Optimized for Fiber to the Home and small-scale ODN signal distribution.

2. High-Density Wiring: The perfect replacement non-uniform FBT fiber splitter for compact distribution boxes and wall-mount cabinets.

3. Enterprise & Infrastructure: Reliable broadband solutions for telecom equipment rooms and residential communities.

Compare with PLC splitter? See our FBT vs. PLC guide below.

FAQ

Q1: What is the difference between FBT Non-uniform Splitters and standard PLC splitters?

A: The primary difference lies in power distribution and flexibility. Standard PLC splitter provides equal 1:N splitting, while our FBT Non-uniform Splitters use high-temperature fusion to achieve precise unequal ratios (1:9, 1:19, etc.). For a detailed FBT vs. PLC Splitter comparison, refer to the table next to this FAQ.

Q2: What custom splitting ratios can you provide?

A: We offer high flexibility for customized projects. Beyond standard 1:9 (10%/90%) and 1:19 (5%/95%), we manufacture custom ratios such as 20/80, 30/70, or any non-uniform FBT fiber splitter specifications your link budget requires.

Q3: What are the advantages of the "Mini" design for installation?

A: Our Ultra-Mini splitters feature compact dimensions non-uniform FBT fiber splitter – significantly smaller than standard housing. This size non-uniform FBT fiber splitter advantage is ideal for high-density wiring in narrow spaces like small wall-mount cabinets and tight telecom rooms.

Q4: What connector types are available for the LF022? Can they be customized?

A: We offer various industrial-standard connectors:

• Standard: SC/APC, SC/UPC

• Optional: LC, FC (Customizable)

• All use 2.5mm Ceramic Zirconia Ferrules for <0.2dB stability.

• Customization: Cable length, jacket type (LSZH/PVC), and fiber type (G.652D/G.657.A).
  This includes support for projects requiring audio/video cable connectors non-uniform FBT fiber splitter compatibility.




Q5: How do you ensure the quality and reliability of each FBT splitter?

A: Quality is our top priority. Every unit undergoes 100% factory testing:

• Optical performance (IL, RL, PDL)

• Environmental testing (-40°C to +85°C)

• Compliance with Telcordia GR-1209/1221-CORE

We also provide reviews non-uniform FBT fiber splitter from verified buyers and offer replacement non-uniform FBT fiber splitter service for warranty cases.

Q6: Can I buy online and check pricing?

A: Yes. You can buy non-uniform FBT fiber splitter directly through our online non-uniform FBT fiber splitter inquiry system. Request a quote for current non-uniform FBT fiber splitter cost based on quantity, ratio, and connector type. Bulk orders enjoy volume discounts.
